Precision dosing pumps for water treatment, wastewater, oil & gas and chemical industry. Mechanical diaphragm, hydraulic diaphragm, piston and solenoid technologies — authorized Doseuro (Italy, member of FPZ Group).
PAC, polymer, NaOCl (bleach), NaOH, H₂SO₄/HCl acid… determine pump head/diaphragm/valve material: PP·PVDF for coagulants; PVDF+PTFE+ceramic ball for NaOCl (avoid SS); PVDF/PTFE for acids.
Required dosing flow (L/h) and back pressure at injection point are the basis for selecting the line: solenoid up to ~22 L/h, mechanical diaphragm 49–1,400 L/h, piston up to 1,458 L/h (AP version up to 230 bar).
Mechanical diaphragm/solenoid for water treatment; hydraulic diaphragm/piston for high-pressure corrosive chemicals; API 675 for oil & gas. Manual or 4–20mA signal control for automation.
Select a dosing pump by three criteria: dosed chemical × flow rate & injection pressure × accuracy/control. The two tables below quickly map mechanism and pump head material.
Click tab to switch view — currently showing by mechanism
| Mechanism | Flow range / pressure | Accuracy | Chọn khi |
|---|---|---|---|
| Solenoid (electromagnetic) | up to ~22 L/h · low pressure | ±~2–3% | very small dosing, intermittent injection, small-scale WWT |
| Mechanical diaphragm (motor-driven) | 49–1.400 l/h | ±~1–2% | water treatment, general chemicals, cost-effective |
| Hydraulic diaphragm | medium–high pressure · sealed (PTFE) | ±1% | leak-free required, corrosive/hazardous chemicals |
| Piston / Plunger | tới 1.458 l/h · bản AP tới 230 bar | ±1% | high pressure, API 675, oil & gas, high accuracy |
| Doseuro lines | Mechanism | Typical applications | SP | Details |
|---|---|---|---|---|
| SR type D | Mechanical diaphragm | Xử lý nước và châm hóa chất phổ thông | 14 | Xem → |
| SR type B | Hydraulic diaphragm | Đầu bơm kín, lưu lượng vừa – lớn | 3 | Xem → |
| SR type BR | Hydraulic diaphragm | Biến thể có van an toàn thủy lực | 3 | Xem → |
| SR type A | Piston/plunger | Small–medium flow | 4 | Xem → |
| SR type AP-A | Piston/plunger · áp cao | Biến thể cao áp của dòng A | 3 | Xem → |
| PDP type A-I | Piston positive-return | Cấu hình API 675 cho dầu khí | 2 | Xem → |
| SR type FM | Mechanical diaphragm | Dải lưu lượng nhỏ | 2 | Xem → |
| SR type SD | Màng thủy lực sandwich | Biến thể màng kép theo cấu hình | 1 | Xem → |
| Chemical / application | Technology | Pump-head material | Note |
|---|---|---|---|
| Clo / Javen (NaOCl) | Diaphragm | PVDF + PTFE + bi gốm | Water disinfection — avoid SS |
| Axit (HCl, H₂SO₄) | Diaphragm | PVDF / PTFE | DO NOT use SS with HCl |
| PAC / polymer (keo tụ) | Mechanical diaphragm | PP / PVDF | WWT — flocculation, medium flow |
| NaOH (caustic soda, pH adjustment) | Diaphragm | PP | PP bền với kiềm |
| Oil & gas / high pressure | Piston (API 675) | 316 stainless steel | ±1% accuracy, high pressure |
General guide — match model to fluid, flow rate and actual pressure: TKT engineer confirms configuration & material →
Series by mechanism & flow rate – pressure range (data from product short descriptions). Click a row for full details.
| Series / Model | Brand | Mechanism | Max flow rate | Max pressure |
|---|---|---|---|---|
| PDP type A-I | Doseuro | High-pressure piston (plunger) | up to 4.000 l/h | up to 250 bar |
| SR type A / AP-A | Doseuro | Diaphragm/piston mechanical (motor) | up to 1.458 l/h | up to 250 bar (AP) |
| SR type B / BR | Doseuro | Diaphragm/piston mechanical (motor) | up to 1.068 l/h | up to 60 bar (AP) |
| SR type D | Doseuro | Diaphragm/piston mechanical (motor) | up to 1.400 l/h | up to 14 bar |
| SR type FM | Doseuro | Diaphragm/piston mechanical (motor) | 14–47 l/h | 5–10 bar |
| SDP type S | Doseuro | Solenoid / small diaphragm | up to 22 l/h | up to 20 bar |
| MX / DM | Nova Rotors | Progressive cavity (PCP) metering | proportional to speed | per model |
Flow/pressure data from each series short description (Doseuro, Italy). 250 bar applies to the AP (high-pressure) version. Submit chemical + flow rate + pressure + concentration for TKT engineers to select the correct mechanism, pump head material, and accessories.
Metering pumps with mechanical and piston diaphragm (motor-driven) — SR series (type A/B/D/FM), PDP high-pressure piston up to 250 bar, and SDP solenoid. Flow up to 4.000 l/h, precision metering per stroke for acids, alkalis, and polymers. TKT distributes genuine stock with CO-CQ documentation.
Thái Khương Pumps distributes genuine Doseuro (Italy) metering pumps — mechanical/piston diaphragm SR, high-pressure piston PDP (up to 250 bar), and solenoid SDP — together with Nova Rotors progressive cavity metering pumps for food/pharmaceutical applications. Supplied with CO-CQ documentation; TKT engineers advise on mechanism, pump head material, and accessories per chemical.
Metering pumps serve wastewater treatment, clean water supply, oil & gas–petrochemical, industrial chemicals, cooling towers and food–pharmaceutical sectors — select mechanism (diaphragm/piston/solenoid) and flow–pressure range to match the chemical.
Dosing PAC coagulant, polymer flocculant, NaOCl disinfectant and pH adjustment at WWTP.
NaOCl disinfection, pH adjustment, scale inhibition for clean water & filtration plants.
Dosing corrosion inhibitors, scale inhibitors, methanol injection to API 675 standard.
Precision dosing of concentrated acids/bases, reagents in manufacturing, electroplating, surface treatment.
Dosing biocide and scale inhibitor for cooling towers.
Precision dosing of additives and CIP cleaning chemicals.
A metering pump (dosing/metering pump) is a positive displacement pump that delivers a precise chemical volume per stroke, providing stable and adjustable flow (typically 1:100 via manual adjustment or 4–20mA signal). Used for dosing coagulants, flocculants, disinfectants, pH correction chemicals, and corrosion inhibitors in water treatment, oil & gas, and industrial applications.
By drive mechanism: mechanical diaphragm (SR type D/FM — common for water treatment, 49–1.400 l/h), hydraulic diaphragm (SR type B/BR — up to 1.068 l/h, AP version up to 60 bar), piston/plunger (SR type A — up to 1.458 l/h, AP version up to 230 bar), electromagnetic solenoid (SDP-S — compact, IP65, up to 22 l/h), and API 675 pump (PDP — oil & gas, 1.5–4.000 l/h, ±1% accuracy).
Pump head, diaphragm, and valve materials must be compatible with the chemical and concentration: PAC/polymer — PP/PVDF; NaOCl (bleach) — PVDF + PTFE diaphragm + ceramic ball (avoid stainless steel); acid H₂SO₄/HCl — PVDF/PTFE; NaOH — PP/PVDF/Stainless Steel 316. Incorrect material selection leads to rapid corrosion and metering errors — TKT engineers provide configuration guidance per process fluid.
API 675 is the American Petroleum Institute standard for metering pumps used in oil refineries, petrochemical plants, and LNG facilities. API 675-compliant pumps guarantee ±1% accuracy across 10–100% of rated capacity, include hydraulic safety relief valves, and incorporate diaphragm rupture detection — commonly required by oil & gas EPC contractors.
A solenoid pump (SDP-S) uses electromagnetism instead of a motor — compact, low-cost, minimal maintenance (no lubrication oil), rated IP65; flow up to 22 l/h, pressure up to 20 bar, suited for small water filters and domestic water treatment stations. A mechanical diaphragm pump (SR-D) uses a motor — flow 49–1.400 l/h, pressure up to 14 bar, suited for larger-scale chemical dosing.
TKT distributes genuine Doseuro metering pumps (Italy, est. 1984, FPZ Group member) — covering the full range from compact solenoid SDP-S, mechanical diaphragm SR-D, hydraulic diaphragm SR-B, piston SR-A to API 675 PDP for oil & gas. TKT provides model and material selection consultation per chemical, quotation, and spare parts. See the Doseuro brand page or call 0941.400.488.
Authorized Doseuro (Italy) metering pumps — mechanical diaphragm, hydraulic diaphragm, piston and solenoid, API 675 certified. Thai Khuong Pumps advises on model selection, pump head material per chemical and provides genuine equipment pricing.
