NM Fire là hãng gì?

CNP NM Fire (Trung Quốc) chuyên bơm chữa cháy đạt UL Listed & FM Approved, chuẩn NFPA 20. Đạt đầy đủ cả UL và FM, sản xuất cả bơm lẫn động cơ diesel đạt UL/FM. Sản phẩm: bơm trục rời, end-suction, trục đứng turbine; cụm bơm diesel/điện, tủ điều khiển, trạm container.

UL / FM / NFPA 20 quan trọng thế nào cho PCCC?

UL Listed và FM Approved là hai chứng nhận quốc tế quan trọng cho thiết bị chữa cháy; NFPA 20 là tiêu chuẩn thiết kế hệ bơm chữa cháy. Nhiều chủ đầu tư, bảo hiểm và đơn vị nghiệm thu PCCC yêu cầu thiết bị đạt các chứng nhận này — giúp hồ sơ nghiệm thu thuận lợi và đảm bảo độ tin cậy khi sự cố.

Chọn bơm trục rời, end-suction, in-line hay turbine?

Split-case (SCF) cho lưu lượng lớn tới 8.000 gpm (nhà máy, KCN); end-suction cho công trình vừa & nhỏ, gọn chi phí (100–2.500 gpm); trục đứng in-line cho không gian hẹp, lắp đứng trên đường ống (50–1.500 gpm); trục đứng turbine (VTP) khi hút từ bể ngầm/giếng sâu (tới 7.500 gpm); kèm bơm bù áp jockey duy trì áp đường ống. Kỹ sư TKT chọn theo lưu lượng, cột áp và nguồn nước của công trình.

Nên dùng cụm bơm diesel hay điện?

Cụm điện phù hợp khi nguồn điện ổn định, chi phí đầu tư thấp hơn, vận hành êm. Cụm diesel (39–1.207 HP, UL/FM) đảm bảo chữa cháy ngay cả khi mất điện — thường bắt buộc cho công trình lớn theo NFPA 20. Nhiều hệ dùng kết hợp điện + diesel + jockey.

NM Fire phù hợp với loại công trình nào?

Bơm chữa cháy NM Fire UL/FM phù hợp công trình yêu cầu nghiệm thu PCCC nghiêm ngặt: nhà máy & khu công nghiệp (split-case + cụm diesel dự phòng mất điện); nhà cao tầng & trung tâm thương mại (in-line/end-suction + jockey); dầu khí & hoá dầu (turbine/diesel, khu vực nguy cơ cao); sân bay & hạ tầng (turbine hút bể ngầm). TKT tư vấn cấu hình theo lưu lượng/cột áp và cung cấp hồ sơ UL/FM cho nghiệm thu.

Thái Khương Pumps hỗ trợ gì cho thiết bị NM Fire?

TKT cung cấp tư vấn kỹ thuật miễn phí (chọn loại bơm, dẫn động, cấu hình theo lưu lượng/cột áp), hồ sơ chứng nhận UL/FM phục vụ nghiệm thu PCCC, báo giá thiết bị chính hãng, lắp đặt, chạy thử và bảo hành nhà sản xuất. Liên hệ 0941.400.488.

UL LISTED · FM APPROVED · NFPA 20 AUTHORIZED GENUINE DISTRIBUTION · TKT

NM Fire

Protecting lives & assets

NM Fire (CNP NM Fire, China) — fire-fighting pumps certified to UL Listed & FM Approved, standard NFPA 20. The manufacturer produces both fire-fighting pumps and diesel engines certified to UL/FM. Pump range includes split-case, end-suction, vertical in-line, vertical turbine and jockey pressure compensation pumps; diesel pump sets and complete containerised pump stations. TKT is the authorized distributor in Vietnam.

Get consultation & quotation View 8 product lines

Factory & industrial zone High-rise & commercial Oil & gas and petrochemical Airport & infrastructure

8.000

max gpm

1.207

HP (diesel)

Certification

Product line

Why NM Fire

Fire-fighting pumps certified to UL / FM full certification

In fire protection, certifications determine project acceptance. NM Fire carries a full set of international certifications for both pumps and engines.

UL Listed & FM Approved

Fire-fighting pumps certified to both major international standards — fully certified to both UL and FM.

NFPA 20 Compliant

Designed, manufactured and tested to NFPA 20 — the international standard for fire-fighting pump systems, facilitating project acceptance.

UL/FM Fire Pump & Diesel Engine

Manufactures both UL/FM fire-fighting pumps and diesel engines — fully integrated pump sets from a single manufacturer.

Full Pump Range

Split-case, end-suction, vertical in-line, vertical turbine (VTP) and jockey pressure maintenance — covering 50–8,000 gpm.

Complete Packages & Container Stations

Diesel/electric pump sets + control panel + jockey pump, pre-assembled on skid; optional container pump station.

Multi-Market International Standards

In addition to UL/FM and NFPA 20, products also comply with EN 12845 (Europe) and GB 6245 — suitable for multiple markets.

Select by project type

Select correctly fire-fighting pump types

Based on flow rate, water source and site layout — select the pump type and drive configuration to suit NFPA 20.

High Flow Rate (Factory/Industrial Zone)

Split-case SCF fire pump — up to 8,000 gpm, high efficiency, easy maintenance.

SCF

Medium & Small Scale, Cost-Efficient

Horizontal end-suction pump — 100–2,500 gpm, compact installation, economical.

End-suction

Suction from underground tank / well

Vertical turbine pump VTP — deep suction, up to 7,500 gpm, minimal footprint.

VTP

Grid-independent

UL/FM diesel engine pump set (39–1,207 HP) — operates during power failure.

Diesel set

Tight Space, Vertical Installation

UL/FM vertical in-line pump — mounted directly on the pipeline, compact footprint (50–1,500 gpm).

In-line

Control & Monitoring

UL/FM fire pump control panel for both electric and diesel, per NFPA 20.

Controller

Fast complete assembly

Pump set pre-assembled on skid or container pump station — reduces construction time.

Container

Pressure maintenance (jockey)

Jockey pressure maintenance pump maintains pipeline pressure, reducing main pump starts.

Jockey

Product categories

3 equipment groups NM Fire

Centrifugal fire pump, complete pump sets & stations and control panels — all UL/FM listed, per NFPA 20.

Centrifugal fire pump · UL/FM

Split-case · End-suction · In-line · Turbine · Jockey

Fire-fighting pump split-case (SCF), end-suction, vertical in-line, vertical turbine (VTP) and jockey pressure maintenance compliant UL/FM, per NFPA 20 — covering flow rates of 50–8,000 gpm.

Flow rate50–8.000 gpm
CertificationUL · FM
StandardNFPA 20
Type5 pump types

Large SCF · compact end-suction · vertical in-line · VTP for underground tank suction · jockey pressure maintenance
UL Listed & FM Approved, designed to NFPA 20

View 5 series

Complete pump sets & pump stations · NFPA 20

Diesel sets · Container stations

Pump set diesel engine (39–1,207 HP) and container pump station pre-assembled: pump + drive + control panel + jockey. Diesel engine also UL/FM listed.

DriveDiesel 39–1.207 HP
CertificationUL·FM·NFPA 20
Complete setPump + engine + panel + jockey
TypeSkid / Container

Diesel operates during power failure — required for many large projects per NFPA 20
Pre-assembled on skid or container pump station — fast installation

View 2 series

Fire pump control panel · UL/FM

Fire Pump Controller

Fire pump control panel listed UL/FM for both electric and diesel pumps, per NFPA 20.

TypeFire-fighting control panel
CertificationUL · FM
ChoElectric & diesel
StandardNFPA 20

Control & monitoring of main pump and jockey
UL/FM listed, compliant with NFPA 20

View 1 series

View full catalog of 8 product lines

Full catalog

Equipment NM Fire at Thái Khương

8 product lines — filter by fire pump group, pump sets & stations, and control panels.

ToFlow rate

8.000gpm

ToDiesel engine

1.207HP

Certification

AvailableSeries

8SP

Filter by group

Fire-fighting pump

Industry application

PCCC cho all project types

UL/FM fire pump for projects requiring strict acceptance inspection.

Factory & industrial zone

High-flow fire pump system for factories, warehouses and industrial zones — split-case SCF pump + diesel backup set for power failure.

SCFDiesel set

High-rise & commercial

Buildings, shopping centers and hotels requiring high head and UL/FM acceptance — in-line/end-suction pump + diesel + jockey per NFPA 20.

In-lineJockey

Oil & gas and petrochemical

High fire-explosion-risk areas requiring full certification — UL/FM turbine/diesel pump for warehouses, ports and petrochemical refineries.

VTPDiesel set

Airport & infrastructure

Airports, ports and key infrastructure projects — vertical turbine pump system for underground tank suction, UL/FM & NFPA 20.

VTPSCF

Capabilities & certifications

Why trust us NM Fire

Full international certification for both pump and engine, large-scale manufacturing to NFPA 20 standards.

UL · FMCertification

Pump & diesel engine

UL ListedFM Approved

NFPA 20Standards

Fire-fighting pump system design

NFPA 20EN 12845 · GB 6245

FactoryChangsha, TQ

Production capacity

100.000+ m²3.000+ sets/year

Product rangeProject coverage

All fire-fighting scales

50–8.000 gpmdiesel 1.207 HP

Trusted by global corporations

About the brand

Experts UL/FM fire pump

CNP NM Fire holds full certification for both UL and FM, and manufactures both fire-fighting pumps and diesel engines to UL/FM. Products comply with NFPA 20, EN 12845 and GB 6245.

Products include split-case pump, end-suction, vertical in-line, vertical turbine, jockey pressure maintenance; complete diesel pump sets, container pump stations and control panels — compliant with NFPA 20, for projects requiring strict fire-safety acceptance.

Distributor in Vietnam

TKT supplies NM Fire fire-fighting pumps genuine, with technical consultation on configuration selection by project flow rate/head, UL/FM certification documentation for acceptance, installation, commissioning and manufacturer warranty.

0941.400.488

Genuine UL · FM NFPA 20

Frequently Asked Questions

Pump FAQ NM Fire

What kind of manufacturer is NM Fire?

CNP NM Fire (China) specializing in fire-fighting pumps listed UL Listed & FM Approved, per NFPA 20. Holds full UL and FM certification, manufactures both pump and diesel engine to UL/FM. Products: split-case pump, end-suction, vertical turbine; diesel/electric pump sets, control panels, container stations.

How important are UL / FM / NFPA 20 for fire protection?

UL Listed and FM Approved are two important international certifications for fire-fighting equipment; NFPA 20 is the design standard for fire-fighting pump systems. Many project owners, insurers, and fire safety acceptance authorities require equipment to meet these certifications — facilitating acceptance inspections and ensuring reliability in emergencies.

Should I choose split-case, end-suction, in-line or turbine pumps?

Split-case (SCF) for high flow rates up to 8,000 gpm (factories, industrial zones); end-suction for medium & small projects, cost-efficient (100–2,500 gpm); vertical in-line for tight spaces, vertical installation on pipeline (50–1,500 gpm); vertical turbine (VTP) when drawing from underground tank/deep well (up to 7,500 gpm); with jockey pressure maintenance pump to maintain pipeline pressure. TKT engineers select based on project flow rate, head and water source.

Should I use a diesel or electric pump set?

Electric pump set suitable when power supply is stable, lower capital cost, quiet operation. Diesel pump set (39–1,207 HP, UL/FM) ensures fire suppression even during power failure — typically required for large projects per NFPA 20. Many systems use a combined electric + diesel + jockey configuration.

What type of projects is NM Fire suitable for?

NM Fire UL/FM fire pump is suitable for projects requiring strict fire-safety acceptance: factories & industrial zones (split-case + diesel set), high-rise buildings & commercial facilities (in-line/end-suction + jockey), oil & gas and petrochemical (turbine/diesel), airports & infrastructure (turbine drawing from underground tank). TKT advises on configuration by flow rate/head and provides UL/FM documentation for acceptance.

What support does Thái Khương Pumps provide for NM Fire equipment?

TKT provides free technical consultation (selecting pump type, drive and configuration by flow rate/head), UL/FM certification documentation for fire safety acceptance, genuine equipment quotation, installation, commissioning, and manufacturer warranty. Contact 0941.400.488.

Free Technical Consultation

Request a quotation fire-fighting pump NM Fire?

Thái Khương Pumps engineers advise on pump type, drive and configuration selection by project flow rate/head — with UL/FM certification documentation for fire-safety acceptance.

0941.400.488 Send quote request
