Bơm dẫn động từ đa tầng cánh Finish Thompson MSDB 2P
In stock · Official distribution
Certification
CE UKCA EAC ATEX (tùy chọn)
Finish Thompson, Inc. (FTI) MSKC Series

Finish Thompson Magnetic Drive Centrifugal Pump Series MSKC

Finish Thompson MSKC Series Magnetic Drive Centrifugal Pump is a sealless magnetic drive centrifugal pump series (no mechanical seal) from Finish Thompson (FTI, USA). The MSKC series comprises 1 model with flow rate up to 13.6 m³/h, head up to 30.4 m, operating temperature up to 104.0°C. Wetted materials: PVDF, PP. Magnetic coupling eliminates seal leakage — safe for corrosive and hazardous chemicals. Officially distributed in Vietnam by Thái Khương Pumps.

13.6m³/h
Max flow rate
30.4m
Max head
104.0°C
Temperature
1model
Quantity
Official FTI distribution since 2022 Sealless pumps Engineers on duty 24/7

Finish Thompson MSKC Series

  • Phân loại: MSKC Sealless Centrifugal Pumps
  • Series: Sealless Pumps
  • Brand: Finish Thompson
  • Origin: USA
  • Ứng dụng: Xử lý hoá chất, xử lý nước, bơm áp cao…
  • Sản phẩm được phân phối chính thức tại Việt Nam bởi Thái Khương Pumps

Technical specifications

  • Lưu lượng tối đa: 12.8 m³/h
  • Cột áp: 21.3 m
  • Nhiệt độ tối đa: 180°F (82°C) – Polypropylene 220°F (104°C) – PVDF
  • Áp suất tối đa: 80 psi
Request a Quote📞 0941.400.488
TK
Application engineer on duty 15-min response · Mon–Sat
Hotline 0941.400.488
Request a Quote
Free consultation Datasheet
SKU: FTI-MSKC-SERIES Categories: , Brand:

01 · Datasheet

Thông số kỹ thuật

MSKC
13.6 m³/h · 30.4 m

02 · Applications

Lĩnh vực suitable

Corrosive chemicals

Transfer of corrosive acids, alkalis and solvents. Sealless magnetic-drive design — no mechanical seal, eliminating leakage and vapor emission of hazardous chemicals.

Khám phá →

Electroplating & surface finishing

Recirculation, filtration and transfer of plating solutions (nickel, chrome, acid). The ETFE-lined UltraChem UC line and Penguin filtration systems are dedicated to plating tanks.

Khám phá →

Wastewater treatment

Chemical dosing, inter-tank transfer and neutralizing-solution pumping. The sealless DB/SP lines are durable with water-treatment chemicals.

Khám phá →

High viscosity & drums

Draw from drums/IBC totes of plastics, glue, resin and oil. The HVDP screw drum-pump line handles viscosities up to 100,000 cP.

Khám phá →

05 · Related products

Products cùng dòng

Bơm Thùng Phuy Dòng BT - Finish Thompson
In stock FTI-BT-SERIES

Drum Pump BT Series - Finish Thompson

—→
Bơm ly tâm dẫn động từ Finish Thompson MSDB Series
In stock FTI-MSDB-SERIES

Finish Thompson MSDB Series Motor-Driven Centrifugal Pump

—→
Bơm thùng phuy Finish Thompson TBS
In stock FTI-TBS

Finish Thompson TBS Drum Pump

—→
Bơm ly tâm dẫn động từ Finish Thompson UC Series
In stock FTI-UC-SERIES

Finish Thompson UC Series Motor-Driven Centrifugal Pump

—→
Buồng lọc than hoạt tính Finish Thompson 4CT-2
In stock FTI-4CT2

Finish Thompson 4CT-2 Activated Carbon Filter Chamber

—→
Bơm ly tâm dẫn động từ Finish Thompson AV Series
In stock FTI-AV-SERIES

Finish Thompson AV Series Motor-Driven Centrifugal Pump

—→
Bơm Thùng Phuy Dòng TT - Finish Thompson
In stock FTI-TT-SERIES

Drum Pump TT Series - Finish Thompson

—→
Bơm thùng phuy Finish Thompson SFP
In stock FTI-SFP

Finish Thompson SFP Drum Pump

—→

03 · Thai Khuong Capabilities

Real people · Real work · Real projects

Visit our HCMC warehouse, technical team, test lab, and 12,000+ projects delivered with Finish Thompson across Vietnam.

19+Years of experience
12k+Projects delivered
5k+SKUs in stock
View Capabilities
Warehouse & team video · 2:14

05 · FAQ & Quote

Questions frequently asked

Is the MSKC still available?
Yes. Finish Thompson positions the DB/MSDB series as the successor generation, but still supplies and supports KC/MSKC — suitable when replacement parts or compatibility with existing KC/MSKC systems are required. New projects should consider the MSDB.
How does the MSKC differ from the MSDB?
Both are seal-less PP/PVDF multistage magnetic drive pumps for high head – low flow rate (~30 m). MSKC belongs to the earlier KC series; MSDB is a newer platform (based on DB11/15) achieving higher head (up to ~93 m). FTI recommends MSDB for new projects.
What is the temperature rating of the MSKC?
The MSKC plastic casing withstands temperatures up to 180°F (~82°C) with PP and 220°F (~104°C) with PVDF. Select material based on the chemical and actual operating temperature of your application.
Is the MSKC magnetic drive pump available in stock in Vietnam?
Thai Khuong Pumps has been the authorized representative of Finish Thompson Inc. (USA) in Vietnam since 06/2022. The HCMC warehouse keeps the common lines in stock; models not in stock are ordered from the FTI factory (Erie, Pennsylvania) with CO-CQ. Call 0941.400.488 to check stock.
What is the warranty period for the MSKC pump?
A 12-month warranty in Vietnam through Thai Khuong Pumps (authorized Finish Thompson representative) covers material/workmanship defects when genuine spare parts are used — with parts and technical support included.
Is there a datasheet and technical support for the MSKC series?
Yes. TKT engineers provide the original Finish Thompson datasheet (performance curves, dimensions, wetted materials) and advise on model selection for the MSKC series based on chemical compatibility. Click the Datasheet button on the page or call 0941.400.488.

01 · Mô tả chi tiết

Thông tin sản phẩm

Bơm dẫn động từ Finish Thompson dòng MSKC

Series MSKC là bản đa cấp của dòng KC (nhựa PP/PVDF), cho cột áp cao – lưu lượng nhỏ. Finish Thompson định vị DB/MSDB là thế hệ kế nhiệm nhưng vẫn cung cấp và hỗ trợ KC/MSKC. Seal-less, không phốt, không rò rỉ. Cột áp ~30 m, áp tới 80 psi.

Cấu tạo & nguyên lý hoạt động

  • Đa cấp dòng KC (nhựa PP/PVDF) — cột áp cao, lưu lượng nhỏ.
  • Seal-less mag-drive — không phốt, không rò rỉ.
  • PP chịu tới 180°F (~82°C), PVDF tới 220°F (~104°C).
  • FTI khuyến nghị MSDB cho dự án mới; MSKC dùng cho thay thế/tương thích hệ cũ.

Bảng thông số các model dòng MSKC

Model Lưu lượng tối đa (m³/h) Cột áp tối đa (m) Nhiệt độ (°C)
MSKC 13,6 30,4 104

Vật liệu tiếp xúc: PP (180°F) / PVDF (220°F). Dải số là tối đa theo từng cấu hình — không phải một model đạt đồng thời. Gửi tên hóa chất + lưu lượng/cột áp để kỹ sư TKT chọn đúng model.

Typical applications

Thay thế, bảo trì các hệ thống đang dùng KC/MSKC; ứng dụng cột áp cao – lưu lượng nhỏ trong dây chuyền hóa chất hiện hữu.

Chọn model nào?

  • Tương thích hệ KC cũ: MSKC.
  • Dự án mới cột áp cao: nên dùng MSDB (kế nhiệm).

Liên kết liên quan

Nguồn thông số: datasheet Finish Thompson (finishthompson.com / ftiair.com). Phân phối chính thức tại Việt Nam bởi Thái Khương Pumps — hỗ trợ kỹ thuật, phụ tùng và báo giá.
