MBS S.r.l. (Parma, Italy — member CSF Inox Group) manufactures tubular heat exchangers (shell-and-tube corrugated tube) and scraped-surface heat exchanger (scraped-surface) in stainless steel for food, beverage, pharmaceutical and industrial applications. TKT is the authorized distributor in Vietnam.
Why corrugated tube efficient heat exchange
MBS developed the corrugated tube together with the University of Parma — converting laminar flow into turbulent flow to improve heat transfer efficiency.
Corrugated tube
Tube surface with corrugated profile instead of smooth tube — induces turbulence even at low velocities.
Turbulent flow
Turbulence breaks the boundary layer — increases heat transfer coefficient, reduces fouling, improves self-cleaning.
High efficiency, more compact
For the same thermal duty, the unit is smaller and lighter than smooth-tube exchangers — saving space and cost.
Thermal expansion compensation & hygiene
Corrugated tubes self-compensate for thermal expansion; hygienic design 3-A/EHEDG, pharmaceutical lines feature double tube sheets to prevent cross-contamination.
4 heat exchanger product lines MBS
From the hygienic Mixflo and industrial Crossflo/Multiflo to the pharmaceutical Pharmaflo and Hercules scraped-surface for viscous products.
Mixflo (MNW · MLW · MLC · MLD)
Equipment hygienic tubular heat exchanger — single tube (MNW), multi-tube (MLW), annular space (MLC), dismountable (MLD). MLW meets EHEDG & 3-A.
- MaterialsAISI 304/316L
- Pressureup to 10 bar
- Temperatureup to 184°C
- Surface roughnessRa <0.8 µm
- Corrugated tube — high efficiency, fouling resistant
- For milk, juice, beer, food liquids
Crossflo · Multiflo (MLI · MLM · MLU)
Equipment industrial tubular heat exchanger — Crossflo (MLI) high pressure/temperature, Multiflo (MLM/MLU) straight or U-shaped installation for oil, chemicals, process water.
- Pressureup to 16 bar
- Temperatureup to 210°C
- MaterialsAISI 304/316L
- InstallationStraight / U-shaped
- Crossflo MLI for high pressure & temperature
- ATEX configuration for flammable media
Pharmaflo (MLP)
Heat exchanger pharmaceutical grade — seamless AISI 316L tube, double tube sheet to prevent cross-contamination, electropolished Ra <0.5 µm. Meets EHEDG & 3-A.
- MaterialsSeamless 316L tube
- Tube plateDouble tube sheet
- Surface roughnessRa <0.5 µm EP
- StandardEHEDG·3-A
- Cross-contamination prevention for pharmaceutical fluids & WFI
- Full material traceability
Hercules (scraped-surface)
Equipment scraped-surface heat exchanger (SSHE) for products high viscosity, with particles — tomato paste, mayonnaise, ricotta, chocolate, ice cream. Detectable PEEK scraper blades.
- Area0.5–4.5 m²
- Power5.5–22 kW
- Temperature−30…+180°C
- Scraper bladeDetectable PEEK
- Single/double wall
- Batch → continuous conversion for viscous products
Heat exchanger MBS at Thái Khương
Flow-through filtering — Mixflo (sanitary), Crossflo/Multiflo (industrial), Pharmaflo (pharma), Hercules (scraped-surface).
Mixflo MLC (Annular Gap)
View details
Mixflo MLD (Removable Tube Bundle)
View details
Mixflo MLW (Tube Bundle)
View detailsMixflo MNW (Single Tube)
View detailsCrossflo MLI
View details
Multiflo MLM
View details
Multiflo MLU
View detailsPharmaflo (pharmaceutical)
View detailsHercules (scraped-surface)
View detailsHeat exchange for processing & utilities
Heating, cooling, pasteurisation, sterilisation (UHT) for liquid products — including viscous and particulate products.
Food & beverage
Pasteurisation of milk, juice, beer; heating/cooling of sugar syrup, sauce, yoghurt. Mixflo sanitary 3-A, corrugated tubes for fouling resistance.
Pharmaceuticals
Heating/cooling of pharmaceutical liquids, WFI. Pharmaflo seamless 316L tubes, double tube sheet for cross-contamination protection, electropolished Ra<0.5µm, EHEDG+3-A.
Industrial & chemical
Heat exchange for oil, chemicals, process water at high pressure/temperature. Crossflo/Multiflo up to 16 bar, 210°C; ATEX configuration.
Viscous & particulate products
Heating/cooling of tomato paste, mayonnaise, ricotta, chocolate, ice cream. Hercules scraped-surface heat exchanger, detectable PEEK scraper blades, −30…+180°C.
Experts heat exchange from Italy
MBS S.r.l. founded in 1995 in Parma, Italy — specialising in shell-and-tube heat exchangers with corrugated tube technology, and scraped-surface heat exchangers for viscous and particulate products. Calculation software co-developed with the University of Parma.
MBS joined CSF Inox Group in 2008 — alongside CSF Inox (pumps), OMAC (lobe pumps) and Bardiani (valves). Products certified to 3-A, EHEDG, PED, ATEX and ASME U-stamp (Hercules series).
MBS
TKT supplies MBS heat exchangers genuine, directly imported from Italy, with technical consultation, thermal sizing, installation, commissioning and manufacturer warranty.
Equipment Q&A MBS
What equipment does MBS manufacture?
What is corrugated tube technology?
Do MBS heat exchangers meet hygiene standards?
Which MBS line should I choose for my product?
What products is the Hercules scraped-surface suitable for?
What support does Thái Khương Pumps provide for MBS equipment?
Request a quotation equipment MBS?
Thái Khương Pumps engineers provide thermal sizing consultation (flow rate, inlet/outlet temperature, fluid type) — quotation for genuine MBS equipment for your project.
