CSF Inox S.p.A. (Montecchio Emilia, Italy — 1970) manufactures stainless steel sanitary pumps for the food, dairy, beverage, pharmaceutical and chemical industries. The product range includes centrifugal pump, positive displacement pump (screw/sinusoidal) and pneumatic piston pump — over 600 pump configurations. TKT is the authorized distributor in Vietnam.
Experts stainless steel sanitary pump since 1970
One manufacturer, three pump technologies — covering every sanitary pumping requirement in food processing, dairy, pharmaceutical and chemical applications.
Over 600 pump configurations
Centrifugal, positive displacement and pneumatic ranges with hundreds of configurations — select the right pump for each fluid and flow rate.
3-A & EHEDG hygienic
CSA, ASH and CN series are 3-A and EHEDG certified; polished surfaces, CIP/SIP — for food, dairy and pharmaceuticals.
Flow rate up to 500 m³/h
CS centrifugal pump up to 500 m³/h, head up to 100 m; CSM/CV multistage series reaches high pressure for large systems.
Self-priming & high viscosity
A/AS series liquid-ring self-priming; M-Series & SN positive displacement pumps for high-viscosity, particle-laden fluids with smooth metering.
Material & ATEX
AISI 304/316L standard, FDA/USP Class VI elastomers; ATEX configuration for hazardous areas.
Member of CSF Inox Group
Together with OMAC (lobe pumps), MBS (heat exchangers) and Bardiani (valves) — an integrated processing equipment ecosystem.
Pump centrifugal vi sinh
Seven centrifugal series — from general-purpose single-stage volute, high-head multistage, to self-priming and 3-A/EHEDG certified series.
CR Series
Centrifugal pumps single-stage volute large inlet port — pumps liquids with solid particles, with minimal product damage.
- Flow rateup to 150 m³/h
- Headup to 20 m
- Pressureup to 2 bar
- Inlet portLarge
- Open impeller — pumps liquids with particles and fibers
- AISI 316L casing, sanitary connections
CS · CSX · CSK · CSD
Main sanitary centrifugal series — up to 500 m³/h, head up to 100 m, 29 sizes. CSK aseptic version for sterile zones.
- Flow rateup to 500 m³/h
- Headup to 100 m
- Pressureup to 10 bar
- Number of sizes29
- High efficiency, sanitary polished surfaces
- CSK aseptic · CSD variant in the same family
CSM · CV Series
Centrifugal pumps multistage for high head — CSM up to 150 m; CV compact monobloc for circulation systems.
- Flow rateup to 50 m³/h
- Headup to 150 m
- Pressureup to 15 bar
- Designup to 40 bar
- High head for CIP, RO, pressure boosting
- AISI 316L, sanitary connections
CN · CL · CLC Series
Centrifugal pump with rolled sheet stainless steel — economical solution for utilities & fluid transfer. CN is 3-A certified.
- Flow rateup to 75 m³/h
- Head>60 m
- Temperature−10…120°C
- StandardCN 3-A
- Cost-effective, flexible installation
- CN sanitary series is 3-A certified
CP Series
Pump peripheral (peripheral impeller) — low flow rate, high pressure up to 16 bar, for metering & pressure boosting.
- Flow rateup to 6 m³/h
- Pressureup to 16 bar
- Temperature−10…100°C
- MaterialsAISI 316
- High pressure at low flow rate
- Suitable for pressure boosting, boilers, small CIP
A · AS Series
Centrifugal pumps liquid-ring self-priming — air priming, pumps gas-entrained liquids; AS high-sanitary version. ATEX configuration.
- Flow rateup to 50 m³/h
- Headup to 35 m
- Pressureup to 3.5 bar
- StandardATEX 3G
- Self-priming, suction from submerged tanks, handles gas entrainment
- A industrial · AS food sanitary
CSA · ASH Series
Centrifugal series EHEDG & 3-A certified — CSA up to 300 m³/h; ASH self-priming 3-A. For dairy & pharma.
- Flow rateup to 300 m³/h
- Headup to 100 m
- Pressureup to 10 bar
- StandardEHEDG·3-A
- High hygiene level in the range — dairy, pharma, WFI
- ASH self-priming, 3-A certified
Pump positive displacement for viscous fluids
Eccentric screw pump (M-Series) and sinusoidal rotor (SN) for high-viscosity, particle-laden fluids — steady flow rate, smooth metering.
M-Series
Pump eccentric screw (progressive cavity) — steady flow rate, pumps high-viscosity fluids with particles & fibers.
- Pressure6 bar/stage
- Viscosityup to 800,000 cP
- MaterialsAISI 316L
- MediumViscous, particle-laden
- Flow rate proportional to speed — smooth metering
- MA/MC/MCR/MI/MAV variants by fluid
SN Series
Pump sinusoidal rotor — smooth flow, low pulsation, pumps highly viscous & shear-sensitive fluids; CIP/SIP.
- Flow rate0–100 m³/h @5 bar
- Pressureup to 15 bar
- Viscosityup to 1,000,000 cP
- Temperature−10…+90°C
- Gentle on product, self-priming
- CIP/SIP sanitary, AISI 316
Pump pneumatic piston
PA/PAR double-acting pneumatically driven piston pump — high pressure up to 150 bar, no electricity required, suitable for ATEX areas.
PA · PAR Series
Pump pneumatically driven piston double-acting — high pressure up to 150 bar, no electricity required, ATEX safe.
- Flow rate1–80 l/min
- Pressure0–150 bar
- MaterialsAISI 304/316
- StandardATEX
- No electricity required — safe in hazardous areas
- High-pressure chemical and solvent pump
Centrifugal pump series CSF at Thái Khương
13 centrifugal series — filter by family: CR, CS/CSK, multistage, sheet stainless steel, peripheral, self-priming, certified.
CR sanitary centrifugal pump
View detailsCS sanitary centrifugal pump
View details
CSD sanitary centrifugal pump
View details
CSK sanitary centrifugal pump
View detailsCSM multistage centrifugal pump
View details
CV multistage centrifugal pump
View detailsCL-CLC sheet stainless steel centrifugal pump
View details
CN Stainless Steel Plate Centrifugal Pump
View detailsCP Peripheral Pump
View detailsA Water Ring Self-Priming Pump
View details
AS Water Ring Self-Priming Pump
View details
ASH Certified Self-Priming Pump
View detailsCSA Certified Centrifugal Pump
View detailsSanitary pump for processing
Four sectors where CSF delivers strong performance with 3-A/EHEDG-compliant sanitary stainless steel pumps.
Food & beverage
Pumping juice, milk, beer, wine, sauce, edible oil, and beverages. CS/CSK/CR sanitary series, CSM multistage for high-pressure CIP systems.
Dairy & Pharmaceuticals
Pumping milk, whey, fermentation broth, and sensitive pharmaceutical products. CSA/ASH series with 3-A/EHEDG certification, high-polish finish, CIP/SIP compatible.
Chemicals & Cosmetics
Pumping chemicals, solvents, creams, and viscous gels. M-Series/SN positive displacement pumps for high-viscosity fluids; PA/PAR piston pumps for high pressure, ATEX configuration.
Utility & Self-Priming
Circulation, tank transfer, and sump pumping. A/AS water ring self-priming series; CP peripheral pump for high pressure at low flow; CN/CL economy stainless steel plate.
Sanitary Stainless Steel Pumps made in Italy
CSF Inox S.p.A. founded in 1970 in Montecchio Emilia (Reggio Emilia), Italy — manufacturing sanitary stainless steel pumps for food, beverage, dairy, chemical, and pharmaceutical applications, with over 600 pump models across three technologies: centrifugal, positive displacement, and pneumatic piston.
CSF Inox is the parent company of CSF Inox Group — comprising OMAC (lobe pumps), MBS (heat exchangers), and Bardiani (sanitary valves). Products are 3-A, EHEDG, ATEX, ISO 9001 certified, and use FDA/USP Class VI elastomers.
CSFINOX
TKT supplies CSF Inox pumps genuine, directly imported from Italy, with technical consultation, installation, commissioning, and manufacturer warranty. TKT engineers assist in selecting the right pump technology and materials for your fluid.
Pump FAQ CSF Inox
What pump series does CSF Inox specialize in?
What pump technologies does CSF offer?
Do CSF pumps meet food sanitary standards?
Which CSF centrifugal pump series to select based on your requirements?
Which group does CSF Inox belong to?
What support does Thái Khương Pumps provide for CSF equipment?
Request a quotation pump CSF Inox?
Thái Khương Pumps engineers advise on selecting the right pump technology (centrifugal/positive displacement/pneumatic), series, and materials for your fluid — quotation for genuine CSF Inox equipment for your project.
