Schurco Slurry
Schurco Slurry® (USA, since 1975 — Jacksonville, Florida) — specializing in centrifugal pumps handling abrasive slurry (slurry) for mining, mineral processing, construction materials, energy and heavy industry. Range 7 series: rubber/metal-lined (S/L/H), solid metal bowl unlined (U/P/Z) and vertical cantilever (V) — hi-chrome M09 material, ISO 9001:2015 certified. TKT distributes in Vietnam.
Sludge pump dedicated for abrasive applications
In slurry pumps, wet-end service life & lifecycle cost are decisive. Schurco designs each series for each slurry class.
Slurry specialists since 1975
U.S. manufacturer focused exclusively on slurry pumps — wet-end designs for abrasive & corrosive slurries.
7 series covering every slurry class
Lined (S/L/H), unlined (U/P/Z) and vertical (V) — Slurry Class I–IV, flow rate up to 6,800 m³/h.
Hi-chrome M09 material
High-chrome iron (Cr 32–35%, 450+ HBN, pH 1–14) resistant to abrasion & corrosion; multiple rubber/metal options.
Zero-leak expeller seal
Optional expeller seal operates without seal water — reduces water consumption & slurry leakage.
Optimized service life & maintenance
Large shaft, short overhang, wide clearances reduce internal velocity — less wear, easy field wet-end replacement.
USA · serving ~50 countries
Engineering & manufacturing in the USA (Jacksonville, FL) + South Africa service center, spare parts for ~50 countries.
Select correctly slurry pump series
Based on abrasion class, particle size, head and layout — select the appropriate lined, unlined or vertical series.
Plant-wide workhorse
S Series — lined, Slurry Class I–IV, up to 5,000 m³/h, varied impeller & material options.
High flow rate, high efficiency
L Series — lined, higher efficiency than S, up to 6,800 m³/h for aggregate, FGD, mineral processing.
High head / hydrotransport
H Series — durable metal lining, up to 100 m & 5,170 kPa, series pumping, slurry pressing, long pipelines.
Simple, low-cost
U Series — unlined, solid metal bowl, easy maintenance, up to 1,350 m³/h for sand/gravel, pulp.
Dewatering & high-head dirty water
P Series — chrome-iron, up to 128 m, for mine dewatering, dirty water with light solids.
Large particles · dredging
Z Series — handles very large solid particles, up to 2,730 m³/h for dredging, gravel, slag, sugar beet.
Sump pump, no submerged bearings
V Series — vertical cantilever, no submerged bearings/seals, can run dry, pumps up to 60% solids.
Spare parts & replacement seals
Genuine wet-end wear parts, impellers, liners, expeller/mechanical/stuffing-box seals — optimized lifecycle cost.
3 slurry pump groups Schurco
Lined pumps (S/L/H), unlined pumps (U/P/Z) and vertical pumps (V) — select by abrasion class & site layout.
S · L · H Series — Lined Pumps (Lined)
Series rubber / metal lining for highly abrasive & corrosive slurry: S (workhorse Class I–IV), L (high efficiency, high flow rate), H (high head, hydrotransport / slurry pressing).
- Flow rateup to 6.800 m³/h
- Headup to 100 m
- Discharge port25–550 mm
- Working pressureup to 5.170 kPa
- Replaceable liners extend service life in abrasive slurry — Slurry Class I–IV
- Expeller seal operates without seal water (zero-leak)
U · P · Z Series — Unlined (Unlined)
Bowl casing solid metal, simple & easy to maintain: U (low cost), P (chrome-iron, dewatering & high-head dirty water), Z (large particles, dredging / gravel).
- Flow rateup to 2.730 m³/h
- Headup to 128 m
- Discharge port50–350 mm
- MaterialsHi-Chrome M09
- Varied metallurgy for abrasive / corrosive slurry
- Z Series handles very large solid particles — dredging, gravel, slag
V Series — Vertical (Vertical sump)
Design fully cantilevered, no submerged bearings / seals — eliminates the main failure point of vertical slurry pumps. Runs dry without damage (snore mode), pumps up to 60% solids (w/w).
- Flow rateup to 1,350 m³/h
- Headup to 50 m
- Discharge port40–250 mm
- Depthup to 3,600 mm
- No submerged bearings/seals — reliable in demanding sumps
- Optional agitator keeps solids in suspension around the suction inlet
Sludge pump Schurco at Thái Khương
7 series — filter by lined, unlined and vertical pump group.
H Series high-pressure slurry pump
View details
L Series slurry pump
View detailsS Series Lined Slurry Pump
View details
P Series Chrome-Iron slurry pump
View detailsU Series Unlined slurry pump
View details
Schurco Slurry Z Series plastic-lined pump
View detailsV Series vertical slurry pump
View detailsSlurry pumps for heavy industry
Wherever abrasive solid-liquid mixtures need to be pumped — Schurco has the right series.
Mining & mineral processing
Ore transport, mill discharge, cyclone feed, tailings — highly abrasive slurry. S/L/H lined + Z for large particles.
Sand, gravel & dredging
Sand, gravel, concrete, dredging ponds & rivers — large particles, low NPSH. Z Series and V Series vertical sump pumps.
Energy & FGD
Flue gas desulfurization (FGD), milk of lime, bottom ash & fly ash handling — corrosive slurry. L Series + hi-chrome M09 material.
Heavy industry
Pulp, steel making, slag processing, metal recycling, sugar & chemical industry — corrosive / abrasive slurry. U/P + H high head.
Why trust us Schurco
U.S. slurry specialist manufacturer, proprietary wear-resistant materials, ISO 9001:2015 certified.
Experts U.S. slurry pump
Schurco Slurry® founded in 1975 (formerly S&H Machinery), headquarters & manufacturing at Jacksonville, Florida — one of the few U.S. manufacturers focused exclusively on slurry pumps. The company holds ISO 9001:2015.
The product range includes lined pumps (S/L/H), solid metal bowl unlined pumps (U/P/Z) and vertical cantilever pumps (V), together with proprietary wear-resistant materials hi-chrome M09 and zero-leak expeller seals — serving mining, mineral processing, dredging, energy and heavy industry in ~50 countries.
TKT supplies Schurco slurry pumps genuine, with series selection consultation, wet-end material & seal type selection by slurry type, quotation for equipment & wear parts, installation, commissioning and manufacturer warranty.
Pump FAQ Schurco
What is Schurco Slurry?
What is the difference between lined and unlined slurry pumps?
What is the M09 wear-resistant material?
Which Schurco series should I select for my application?
Which industries use Schurco pumps?
What support does Thái Khương Pumps provide for Schurco equipment?
Request a quotation slurry pump Schurco?
Thái Khương Pumps engineers advise on series selection, wet-end material and seal type by slurry type, particle size and project head — with genuine wear parts.
