Updated: June 2026 · Compiled by: TKT Technical Department
Corrosive chemical transfer — safe, leak-free
Pumps for transferring acid, solvents, corrosive chemicals between storage tanks, drums, IBCs and production lines — safe loading, unloading and dispensing for each fluid.
ATEX Certified · ISO 9001 · FDA Compliant · Zero-Leak — TKT selects the model by each fluid, each transfer route and wetted materials.
Which routes does the chemical travel?
Chemical transfer pumps are a specialized group of pump equipment used to move, transfer or load/unload corrosive chemicals — acid, alkaline, solvents, slurry — between storage tanks, drums, IBC tanks and production line pipework. Unlike standard water pumps, these require wetted materials (pump body, diaphragm, seal, O-ring) compatible with the specific fluid. Selection depends on two main factors: transfer route (fixed tank → continuous piping, or mobile drum/IBC batch transfer) and fluid properties (corrosivity, temperature, viscosity, ATEX/FDA requirements). The four common technologies include: plastic-lined centrifugal (continuous high flow, up to 2,000 m³/h), sealless mag-drive (zero-leak for acid/solvents), air-operated diaphragm pump AODD (mobile drum/IBC, ATEX zone no electricity needed), and drum pump/electric diaphragm pump EODD (when power supply is available).
The route determines the pump. Fixed route, high flow leans toward plastic-lined centrifugal or sealless mag-drive; mobile drum/IBC route leans toward AODD/EODD diaphragm pump or drum pump. Let TKT know the fluid and transfer line to narrow down the right pump category.
How do you need to transfer the fluid?
Select the relevant scenario to view the solution and specific model below.
Corrosive chemical transfer — zero-leak
- Loading/unloading acid, base, plating solution between tank ↔ process line
- Zero-leak requirement
- Continuous transfer, fixed installation on pipeline
- Wetted material PP or PVDF
Continuous transfer tank → process line, high flow rate
- Transferring corrosive chemicals from large tank to process line
- Thermoplastic-lined pump casing (PP/PVDF/PTFE)
- Installed to DIN/EN 22858 · ISO 2858 standard
- High flow rate, continuous, fixed installation
Transfer with electric diaphragm pump — where power is available
- Power available, no compressed air desired
- Batch transfer, drum/IBC suction, self-priming, dry-run capable
- Saves compressed air compared to AODD
- Fluid with light solids, moderate viscosity
Mobile drum / IBC transfer — no electricity
- Solvent and flammable chemical transfer — ATEX required
- No electricity, compressed air only
- Fluid with solids/slurry or dry-run risk
- Mobile drum/IBC transfer, self-priming
Selecting a transfer pump requires full transfer context
Which fluid, from where to where (tank ↔ drum ↔ IBC ↔ process line), flow rate and wetted material — all affect the right model. Every wetted component — pump casing, diaphragm, O-ring, gasket, flexible hose — must be checked for compatibility. TKT requires full specifications before recommending a model.
Model suited to each transfer line
5 pump categories commonly used for corrosive chemical transfer — click each brand to view details.
Which pump model for each transfer method?
Each pump category suits a specific transfer method. TKT provides datasheets for each recommended model. Want to learn more about industrial chemical pump solutions or need a mag-drive sealless pump (Germany)? Inquire about CP Pumps — contact us for datasheets.
- ATEX 94/9/EC
- DIN/EN 22858
- ANSI B73.1
Affetti (Italy) thermoplastic-lined centrifugal pumps operate continuously on fixed pipelines, handling strong acids and solvents at temperatures from −50 to +150°C, suitable for chemical production lines with flow rates from 10 to 2,000 m³/h.
KSP: Materials PP·PP-EL·PVDF·PVDF-EL·PEHD·PVC·PTFE, temperature −50→+150°C; Mag-drive sealless 0.55→18.5 kW; standard DIN/EN 22858·ANSI B73.1; ATEX 94/9/EC version; sump vertical (CGV/CMV) + self-priming (VGA/VMA) suction lift up to 4 m.
TABLE A · Horizontal Centrifugal — DIN/EN 22858 · ISO 2858
| Series | Flow Rate | Head | Power |
|---|---|---|---|
| CFG · CGD · CGO | 10 → 2.000 m³/h | 5 → 120 m | 0.75 → 200 kW |
| ANSI B73.1 | 5 → 56 m³/h | 10 → 42 m | Contact for datasheet |
| CFM · CDM · CMO-N | 10 → 250 m³/h | 6 → 100 m | 2.2 → 75 kW |
| Mag-Drive (sealless) | Contact for datasheet | — | 0.55 → 18.5 kW |
TABLE B · Sump Vertical & Self-Priming
| Series | Flow Rate | Head | Power |
|---|---|---|---|
| CGV-S/N · CMV | 5 → 450 m³/h | 6 → 100 m | 0.55 → 75 kW |
| VGA · VMA (self-priming) | 1.5 → 25 m³/h | 1.5 → 30 m | 0.25 → 5.5 kW |
Note: Per Affetti General Catalogue. Contact TKT to receive datasheets + performance curves for specific models.
- ISO 9001
- CE
- FDA
Finish Thompson (FTI, USA) provides mag-drive sealless pumps for acid/base/solvent transfer — no mechanical seal means zero-leak compliance — and the EFP/TT drum pump line for direct transfer from drums or IBC.
KSP: Mag-drive sealless DB/SP/UC; drum/IBC pump EFP·TT; PVDF resistant to acid/base/chloride/oxidizers; SP self-priming up to 7.6 m lift.
TABLE A · Mag-Drive Sealless — DB / SP / UC (PVDF)
| Series | Type | Flow Rate Range | Material |
|---|---|---|---|
| DB Series | Mag-drive standard | 0.95 → ~1.040 L/min | PP, PVDF |
| SP Series | Mag-drive self-priming | Self-priming up to 7.6 m | PP, PVDF |
| UC Series | Mag-drive heavy-duty | Contact for datasheet | PVDF |
TABLE B · Drum / IBC Pump — EFP / TT
| Series | Type | Notes |
|---|---|---|
| EFP Series | Chemical drum pump | Drains drum/IBC completely · Contact for datasheet |
| TT Series | Chemical drum pump | Batch transfer · Contact for datasheet |
Note: Mag-drive PVDF DB/SP range 0.95 → ~1,040 L/min; drum pump EFP/TT per configuration. SP not recommended for flammable fluids.
- EODD · Electric-Driven
Cognito provides electric diaphragm pumps (EODD) — retaining the self-priming, dry-run and drum/IBC suction characteristics of a diaphragm pump but driven electrically, with no compressed air consumption; specifications vary by configuration, contact for datasheets.
KSP: Electric-driven, no compressed air required; self-priming & dry-run capable, drum/IBC suction; energy-efficient compared to AODD when power is available; wetted material + diaphragm selected by fluid.
TABLE · Cognito EODD — Electric Diaphragm Pump
| Series | Type | Specifications |
|---|---|---|
| Cognito EODD | Electric diaphragm pump (electric DDP) | Contact to receive datasheet |
- Suitable when
- Power supply available
- No compressed air preferred
- Batch transfer
- Drum/IBC suction
- Self-priming/dry-running
Note: Cognito electric diaphragm pump (EODD) — flow rate, pressure and material specifications confirmed per configuration. Contact TKT.
- ATEX
- ISO 9001
- CE
Sandpiper (USA) provides AODD compressed air diaphragm pumps in the S05–S30 range (56–1,078 L/min), air-operated with no electricity — suitable for mobile drum/IBC transfer and areas with solvent vapors requiring ATEX.
KSP: Air-operated, no electricity (safe in solvent vapor zones); self-priming & dry-run (mobile drum/IBC transfer); handles fluids with solids; Metallic (Al/CI/SS) up to 8.6 bar · Non-Metallic (PP/PVDF) up to 7 bar.
TABLE · S Series — AODD Model Lineup
| Model | Port | Max Flow | Solids | Max Pressure |
|---|---|---|---|---|
| S05 M/NM | ½" | 56 L/min | 3 mm | 8.6 / 7 bar |
| S15 M/NM | 1½" | 401 L/min | — | 8.6 / 7 bar |
| S20 Metallic | 2" | 758 L/min | — | 8.6 bar |
| S30 Metallic | 3" | 1.078 L/min | 9.65 mm | 8.6 bar |
| S30 Non-Metal | 3" | 1.060 L/min | 19 mm | 7.0 bar |
Note: Per Sandpiper S05/S15/S20/S30 Metallic & Non-Metallic datasheets. Diaphragm, ball, and valve seat materials must be verified separately for each fluid — contact TKT.
Which pump technology suits each transfer method?
Corrosive chemical transfer requires the right technology — sealless for zero-leak, AODD for mobile drum/IBC, electric diaphragm pump where power is available.
- Mag-drive sealless zero-leak
- PP/PVDF/PTFE lined casing
- DIN/EN 22858 · ANSI B73.1 standard
- ATEX 94/9/EC version
- Mechanical seal is a leak point
- Material grade unspecified
- Periodic seal replacement causes downtime
- No ATEX configuration
- DIN/EN 22858
- ANSI B73.1
- ATEX 94/9/EC
- 10–2.000 m³/h
- PP/PVDF/PTFE
- −50→+150°C
- No electricity, safe in ATEX zones
- Self-priming & dry-run capable
- Handles solids
- Metallic & Non-Metallic
- Electric unsuitable in solvent vapor zones
- Difficult to move
- Many types cannot run dry
- Difficult to handle solids
- S05→S30
- 56–1.078 L/min
- No electricity
- Self-priming/dry-running
- ATEX Ready
- Electric drive, no compressed air required
- Retains diaphragm pump characteristics (self-priming, dry-run, drum/IBC suction)
- Energy-efficient compared to AODD
- Material selected by fluid
- Requires available compressed air (bar, CFM)
- Suitable for no-electricity/solvent vapor zones
- Continuous air consumption
- Also self-priming/dry-run capable
- Electric DDP
- No compressed air required
- Self-priming/dry-running
- Drum/IBC suction
- Contact to receive datasheet
Hands-on technical expertise — no generic sales pitch
TKT distributes brands verified under Vietnamese industrial conditions. Stock on hand, technical engineers assist in selecting the model for each application.
How does your industry need to transfer chemicals?
Chemical transfer pumps — including solvents, paints, inks, and pharmaceutical reagents — require selecting the right wetted material and drive type for each industry. TKT advises on models by specific transfer scenario.
Water treatment & wastewater treatment
Need to transfer PAC/NaOH/coagulant polymer from tank to basin; transfer acid/base wastewater.
GP: Affetti thermoplastic-lined centrifugal pump (PP/PVDF) · FTI SP mag-drive (PVDF, self-priming, zero-leak).
- Thermoplastic-Lined
- Zero Leak
- Self-Priming
Electroplating & surface treatment
Loading/unloading H₂SO₄, HCl, NaOH between tank and plating bath.
GP: FTI DB (PVDF) mag-drive sealless · Affetti thermoplastic-lined centrifugal pump (PP/PVDF/PTFE).
- Sealless
- Zero Leak
- PVDF Grade
Pharmaceutical & lab
Transfer reagent/solvent from carboy/drum to process line; FDA compliance required.
GP: FTI DB (FDA-grade PVDF) · Cognito EODD (batch transfer, self-priming — contact for datasheet).
- FDA Compliant
- Contamination-Free
- Self-Priming
Industrial chemicals
Loading/unloading heavy chemicals (concentrated H₂SO₄, solvents, slurry) between large tanks, high flow rate.
GP: Affetti plastic-lined centrifugal pump (DIN/EN·ANSI, ATEX, 10→2.000 m³/h) · Sandpiper S30 (slurry/solid particles, AODD).
- DIN/EN
- ANSI
- ATEX Ready
- Slurry OK
Paint / Ink & Viscous Fluids
Dispensing paint/ink/solvents/viscous fluids from drums/IBC; ATEX zone.
GP: Sandpiper S-Series (AODD no electricity required, ATEX) · Cognito EODD (when power is available — contact for datasheet).
- ATEX Zone
- Drum/IBC Dispensing
- Viscous Fluids
Your industry not listed? Submit your transfer requirements — TKT will recommend the right model.
Industry consultation →Explore more
Q&A — chemical transfer pump
What is a chemical transfer pump?
Which pump type should be used for transferring corrosive acids/solvents?
Which pump draws directly from a drum / IBC?
How does a corrosive chemical transfer pump differ from a dispensing pump?
What materials offer good chemical resistance for wetted parts?
How should flammable chemical dispensing be handled in ATEX zones?
How does a mag-drive (sealless) pump differ from a mechanical seal pump?
What is used for high-flow transfer from tanks into a production line?
Which brands does TKT supply for chemical transfer?
Submit your transfer requirements — TKT recommends the right model
Fluid to be transferred, source and destination (tank/drum/IBC/line), flow rate and wetted materials — sufficient for TKT to propose the right solution.
- Fluid to be transferred (name, concentration, temperature)
- Transfer from/to: tank / drum / IBC / production line
- Flow rate and wetted materials
- ATEX/zero-leak requirements and available power/compressed air
