TRIPLEX PLUNGER PUMPS K 40000 – 3G – KAMAT

Lưu Lượng Max

m³/h

Áp Suất

bar

Vật Liệu

General product information:

  • Name: TRIPLEX PLUNGER PUMPS K 40000 – 3G
  • Class: PLUNGER PUMPS
  • Type: POSITIVE DISPLACEMENT PUMPS
  • Application: Paint industry, maritime, chemical, cleaning, industrial cleaning…
  • Origin:  Germany
  • Brand: KAMAT
  • The product is officially distributed in Vietnam by Thái Khương Pumps
Technical data:
  • Flow: 58 – 1310 l/min
  • Pressure: 125 – 3500 bar
  • Power input: 315 – 400 kW
  • Weight: 1360 kg

THÔNG SỐ KỸ THUẬT

General product information:

  • Name: TRIPLEX PLUNGER PUMPS K 40000 – 3G
  • Class: PLUNGER PUMPS
  • Type: POSITIVE DISPLACEMENT PUMPS
  • Application: Paint industry, maritime, chemical, cleaning, industrial cleaning…
  • Origin:  Germany
  • Brand: KAMAT
  • The product is officially distributed in Vietnam by Thái Khương Pumps
Triplex plunger pumps K 40000 – 3G is very similar to the K 35000 in respect of the basic areas of application: In main focus are hydraulic hydraulic applications and jetting. In case of jetting, the 400 kW high-pressure pump is frequently installed in large mobile systems. The K 40000 is particularly the choice when, in comparison with the K 35000, the same specific output should be realized at higher pressure. In mining these are, for example, flow rates of between 400 and 600 l/min. With industrial service providers, usually around 200 l/min at approx. 1000 bar. Mostly the pump is used in 24/7 operation. According to layout of the pump heads, the high-pressure pump is suited for pumped media with a viscosity of up to 2,000 mPas (millipascal second) and a fluid temperature of up to 200°C.

Characteristics

  • Gear with forced lubrication
  • With oil cooler
  • Integrated gear reduction-ratio
  • Also available in accordance with API 674 and/or ATEX
  • Special media, such as sea water, glycol, methanol, oils etc., on request
  • Filtration up to 350 µm

Technical data:

Triplex plunger pumps K 40000 - 3G

Triplex plunger pumps K 40000 – 3G structure and installation types:

Cấu tạo bơm K 40000 - 3G Triplex lắp đầu bơm dạng A
Installation type A
Cấu tạo bơm K 40000 - 3G Triplex lắp đầu bơm dạng MC
Installation type MC
Cấu tạo bơm K 40000 - 3G Triplex lắp đầu bơm dạng MCH
Installation type MCH
Cấu tạo bơm K 40000 - 3G Triplex lắp đầu bơm dạng HD và Foot
Installation type HD and Foot
Cấu tạo bơm K 40000 - 3G Triplex lắp đầu bơm dạng M
Installation type M

Triplex plunger pumps K 40000 – 3G:

Triplex plunger pumps K 40000 - 3G

[row][col span__sm=”12″ align=”center”]

More about product’s detailed technical data is here:

[button text=”DOWNLOAD” radius=”99″ link=”https://www.kamat.de/fileadmin/user_upload/DE/01-05-16-Downloads/Hochdruckpumpen/p501.pdf” target=”_blank”][/col][/row]
