EL-ES Series rotary lobe blower - ROBUSCHI

General product information:

Name: ROBOX EL & ES
Class: EL & ES SERIES ROTARY LOBE BLOWERS
Type: AIR BLOWER
Application: Wastewater treatment, aquaculture, air tank...
Origin:  Italia
Brand: ROBUSCHI
The product is officially distributed in Vietnam by Thái Khương Pumps

Technical data:

Flow rate up to: 10.000 m³ / h
Motor power up to: 250 kW
Absolute inlet pressure starting from: 500mbar
Maximum compression ratio, standard model: 2
Maximum temperature 150°C for an ambient temperature up to 50°C
Noise level between 70 and 85 dB (A) (1 m ISO 3746)

10.000m
Lưu lượng
250kW
Công suất
Nhà phân phối ủy quyền Bảo hành chính hãng Kỹ sư trực 24/7

General product information:

  • Name: ROBOX EL & ES
  • Class: EL & ES SERIES ROTARY LOBE BLOWERS
  • Type: AIR BLOWER
  • Application: Wastewater treatment, aquaculture, air tank…
  • Origin:  Italia
  • Brand: ROBUSCHI
  • The product is officially distributed in Vietnam by Thái Khương Pumps

Technical data:

  • Flow rate up to: 10.000 m³ / h
  • Motor power up to: 250 kW
  • Absolute inlet pressure starting from: 500mbar
  • Maximum compression ratio, standard model: 2
  • Maximum temperature 150°C for an ambient temperature up to 50°C
  • Noise level between 70 and 85 dB (A) (1 m ISO 3746)
TK
Kỹ sư ứng dụng đang trực Phản hồi 15 phút · Mon–Sat
Hotline 0941.400.488
Yêu cầu báo giá

03 · Năng lực Thái Khương

Người thật · Việc thật · Dự án thật

Xem kho TP.HCM, đội kỹ thuật, lab test, và 15.000+ dự án đã triển khai trên toàn Việt Nam.

19+Năm kinh nghiệm
15k+Dự án triển khai
5k+SKU sẵn kho
Xem trang Năng lực
Video kho & team · 2:14

05 · FAQ & báo giá

Câu hỏi thường gặp

Sản phẩm có sẵn kho không?
TKT Pumps là nhà phân phối ủy quyền của 28+ thương hiệu bơm công nghiệp EU/G7. Kho TP.HCM duy trì 5.000+ SKU. Liên hệ hotline 0941.400.488.
Bảo hành bao lâu?
Tùy thương hiệu. Sandpiper bảo hành 5 năm. Wilo / Grundfos / Ebara 12-24 tháng.
Có tư vấn kỹ thuật miễn phí?
Có. Đội kỹ sư 24/7 hỗ trợ chọn model + tính thông số. Click Tư vấn miễn phí hoặc gọi hotline.
Bao lâu nhận báo giá?
SLA phản hồi 15 phút. Báo giá đầy đủ kèm datasheet + lead-time gửi trong 24 giờ.
Có Datasheet PDF?
Có. Click Datasheet — kỹ sư TKT gửi PDF gốc + bản vẽ dimension + service manual.

01 · Mô tả chi tiết

Thông tin sản phẩm

General product information:

  • Name: ROBOX EL & ES
  • Class: EL & ES SERIES ROTARY LOBE BLOWERS
  • Type: AIR BLOWER
  • Application: Wastewater treatment, aquaculture, air tank…
  • Origin:  Italia
  • Brand: ROBUSCHI
  • The product is officially distributed in Vietnam by Thái Khương Pumps

The Robuschi RBS is the innovative, positive displacement, rotary blower, especially designed for applications in ROBOX packages.

ROBOX is an integrated compression package for conveying low pressure gases. It is equipped with the RBS positive displacement rotary lobe blower, driven by and electric motor through a custom designed V-belt drive, and comes complete with all the necessary accessories.

The filter is positioned inside the silencer, and fitted to the blower in-let port, minimizing the possibility of contamination of the conveyed gas. ROBOX packages can handle flow rates up to 150m³/min and can be fitted with motors up to 250kW.

The ROBOX package includes: RBS blower, In-let Silencer, In-let Filter, Discharge Silencer, Motor, V-belt Drive, Safety Valve, Check Valve, Unloading Valve and Noise Enclosure with Extraction Fan and Lifting Frame.

EL & ES product technical data:

EL & ES Performance curve
EL & ES Performance curve

EL non-silencer

EL non-silencer
EL non-silencer

ES with silencer

ES with silencer
ES with silencer

[row]

[col span__sm=”12″ align=”center”]

More about product’s detailed technical data is here:

[button text=”DOWNLOAD” radius=”99″ link=”https://www.scot-industrial-air.co.uk/media/139716/Robuschi-blowers-for-sale-Scot-Industrial-Air.pdf” target=”_blank”]
